Modular Barricade Rack - 1 Cylinder Position Deep - Yellow - Gas Cylinder Rack
In stock
Model #
BR1X1VT
$250.00
Call 1-877-805-8650 to order or request quote by phone.
Status:
Built to order
Shipping:
Ships 7-10 weeks from order date. You will be sent a tracking # upon shipment.
Cylinder capacity: 1
Cylinder diameters supported: Up to 13"
Rack configuration: 1 wide x 1 deep (base unit without extensions)
Cylinder diameters supported: Up to 13"
Rack configuration: 1 wide x 1 deep (base unit without extensions)
Rack dimensions:
External:
16.5"w
x
16.5"d x 32"h
Usable bay dimensions: 13.5" wide x 13.5" deep
Usable bay dimensions: 13.5" wide x 13.5" deep
Primary starter rack for a modular barricade rack system. Expand rack capacity by adding compatible extension arms (model # BR1EXTVT) as needed.
Cylinder Rack Features:
- Expandable with add-on extensions
- Supports facility compliance with OSHA, NFPA 1, NFPA 55, and CGA P-1 guidelines
- Steel frame construction
- Two levels of chains
- Two pre-drilled 13/32" diameter floor mounting holes per arm
- Yellow baked-in powder-coated finish
- Bulk cylinder storage
- Industrial and commercial use
- Made in the USA
- Product weight: 36 lbs
Description:
This is the primary starter unit for a modular gas-cylinder barricade rack system. The rack is one bay wide and one cylinder position deep, with capacity for one cylinder. Its primary frame forms the base of wider one-deep configurations; each compatible BR1EXTVT add-on creates one adjacent bay and one additional cylinder position.
The steel frame has a yellow baked-in powder-coated finish for a smooth, durable surface. Its upright, compact layout helps keep the cylinder in a ready storage position without using unnecessary floor space. The rack provides four 13/32" floor-mounting holes. Product dimensions (WxDxH): 16.5" x 16.5" x 32".
This is the primary starter unit for a modular gas-cylinder barricade rack system. The rack is one bay wide and one cylinder position deep, with capacity for one cylinder. Its primary frame forms the base of wider one-deep configurations; each compatible BR1EXTVT add-on creates one adjacent bay and one additional cylinder position.
The steel frame has a yellow baked-in powder-coated finish for a smooth, durable surface. Its upright, compact layout helps keep the cylinder in a ready storage position without using unnecessary floor space. The rack provides four 13/32" floor-mounting holes. Product dimensions (WxDxH): 16.5" x 16.5" x 32".
USA Ref #: CYL-FMSR-1
Get more information:
Call 1-877-805-8650 (M-F, 9-5 p.m. CST) if you have questions about this product.
Call 1-877-805-8650 (M-F, 9-5 p.m. CST) if you have questions about this product.
Secure rack to the ground/floor using the appropriate hardware for the material. Each rack has pre-drilled 13/32" holes in each arm for mounting to ground. It is recommended that a site survey be completed by the authority having jurisdiction to determine the suitability of the barricade racks at that location and to confirm all local regulations are being followed.
If extension bays are purchased, position each extension beside the primary rack, align the adjoining frame members and pre-drilled connection points, and securely bolt the extension to the primary rack or previously installed extension using the supplied connection hardware. After all bays are connected, anchor each frame arm to the ground/floor and confirm that the complete assembly is level, stable, and securely fastened before loading cylinders.
Includes a 90-day limited warranty covering defects in material and workmanship on original components, subject to the warranty terms and exclusions.
Ships on a pallet by freight truck.
