16 Propane Tanks (33-43 LB) - Outdoor - Vertical Storage - 2 Compartments - 4 Doors - Steel & Mesh - Gas Cylinder Cage
In stock
Model #
CBV16442MDAAM
$3,130.00
Call 1-877-805-8650 to order or request quote by phone.
Status:
Built to order
Shipping:
Ships 2-3 weeks from order date. You will be sent a tracking # upon shipment.
Cabinet capacity: 16 cylinders (33-43 lb) of 12.5" diameter
Cabinet dimensions:
121"w x 30"d x 53"h
Gas Cylinder Locker Features:
- Gas cylinder locker meets OSHA 1910 and NFPA regulations
- 2 separate compartments
- Lockable double doors with heavy duty lock receiver (lock not included)
- 8" stainless steel door hinges
- Mesh sides and door allow visibility into cabinet
- Door and sides painted white with hi-build electrostatic powder coating
- Top and back are solid galvanized steel
- 3/16" Aluminum diamond floor plate
- Pre-drilled holes (13/16") for anchoring each foot pad
- Powder coated with outdoor grade paint for extra durability
- Safety signage included
- Ships in 2 pieces, minor assembly required
- Product panels bolt together and can be disassembled
- Made in the USA
- Product weight: 555 lbs
16 Propane Tanks (33-43 LB) - Outdoor - Vertical Storage - 2 Compartments - 4 Doors - Steel & Mesh - Gas Cylinder Cage
Model #
CBV16442MDAAM
Description:
The cabinet holds up to 16 propane tanks (33-43 LB) in a vertical position (8 cylinders per compartment). It can also hold 20 lb cylinders. The cabinet doors and side panels are made with formed galvannealed steel angles and galvanized expanded metal that is coated with hi-build electrostatic powder coating. The top and back of the cabinet is made from solid galvanized steel panels. This unit has 2 compartments and 2 doors per compartment which use tamper-resistant stainless steel hinges and have a heavy duty lock receiver (lock is not included). The cabinet floor is bright 3/16" aluminum diamond plate. "Propane - No Smoking" and 2-4-0 OSHA Diamond signage is included. Each footpad on the cage has one 13/16" pre-drilled hole to accommodate an anchor bolt. Meets OSHA and NFPA requirements for LP fuel cylinder storage. Ships in 2 pieces, minor assembly required. Shelf weight capacity 300 lbs. Cabinet external dimensions (WxDxH): 121" x 30" x 53", Single Compartment Internal: 57.5"x26"x46.75"
MPN: FV16442MDA
Get more information:
Call 1-877-805-8650 (M-F, 9-5 p.m. CST) if you have questions about this product.
Call 1-877-805-8650 (M-F, 9-5 p.m. CST) if you have questions about this product.
Place cabinet on level surface. Cabinet frame bolts (9/16") can be loosened to shift the panels if needed to level the cabinet to the ground surface or square up the door. The cabinet lower corners have foot-pads with a pre-drilled 13/16" hole that can be used to anchor the cabinet if required. It is suggested that the cabinet be anchored to the mounting surface. Check with your authority having jurisdiction to confirm anchoring is required. Use the appropriate hardware for the mounting surface. Mounting hardware not included.
1 year warranty against manufacturing defects.
Ships fully assembled on a pallet by freight truck. Loading dock or forklift required for delivery. If neither are available please request liftgate delivery at time of order.
