16 Propane Tanks (33-43 LB) - Outdoor - Vertical Storage - 2 Compartments - 4 Doors - Laser Cut Aluminum - Gas Cylinder Cage
In stock
Model #
CBALV16442MDAAM
$3,130.00
Call 1-877-805-8650 to order or request quote by phone.
Status:
Built to order
Shipping:
Ships 1-2 weeks from order date. You will be sent a tracking # upon shipment.
Cabinet capacity: 16 cylinders (33-43 lb) of 12.5" diameter
Cabinet dimensions:
121"w x 30"d x 53"h
Gas Cylinder Locker Features:
- Gas cylinder locker meets OSHA 1910 and NFPA regulations
- Two compartments
- Lockable double doors (lock not included)
- 8" stainless steel door hinges
- Aluminum door and sides with laser cut holes for ventilation
- Top and back are solid aluminum panels
- Pre-drilled holes (13/16") for anchoring each foot pad
- Safety signage included
- Two cabinets ship assembled and bolt together
- Ships in 2 pieces, minor assembly required
- Made in the USA
- Product weight: 455 lbs
16 Propane Tanks (33-43 LB) - Outdoor - Vertical Storage - 2 Compartments - 4 Doors - Laser Cut Aluminum - Gas Cylinder Cage
Model #
CBALV16442MDAAM
Description:
The cabinet holds up to 16 propane tanks (33-43 LB) in a vertical position (8 cylinders per compartment). It can also hold 20 lb cylinders. The cabinet doors and side panels are made with laser cut aluminum panels. The top and back of the cabinet is made from solid aluminum panels. There are two compartments with two double doors on this unit, which have tamper-resistant stainless steel hinges and are lockable (lock is not included). Includes bright 3/16" aluminum diamond floor plate. "Propane - No Smoking" and 2-4-0 OSHA Diamond safety signage is included. Each footpad on the cage has one 13/16" pre-drilled hole to accommodate an anchor bolt. Meets OSHA and NFPA requirements for LP fuel cylinder storage. Ships in 2 pieces, minor assembly required. Shelf weight capacity 300 lbs. Cabinet external dimensions (WxDxH): 121" x 30" x 53", Single Compartment Internal: 57.5"x26"x46.75"
The cabinet holds up to 16 propane tanks (33-43 LB) in a vertical position (8 cylinders per compartment). It can also hold 20 lb cylinders. The cabinet doors and side panels are made with laser cut aluminum panels. The top and back of the cabinet is made from solid aluminum panels. There are two compartments with two double doors on this unit, which have tamper-resistant stainless steel hinges and are lockable (lock is not included). Includes bright 3/16" aluminum diamond floor plate. "Propane - No Smoking" and 2-4-0 OSHA Diamond safety signage is included. Each footpad on the cage has one 13/16" pre-drilled hole to accommodate an anchor bolt. Meets OSHA and NFPA requirements for LP fuel cylinder storage. Ships in 2 pieces, minor assembly required. Shelf weight capacity 300 lbs. Cabinet external dimensions (WxDxH): 121" x 30" x 53", Single Compartment Internal: 57.5"x26"x46.75"
MPN: A-FV16442MDA
Get more information:
Call 1-877-805-8650 (M-F, 9-5 p.m. CST) if you have questions about this product.
Call 1-877-805-8650 (M-F, 9-5 p.m. CST) if you have questions about this product.
Place cabinet on level surface. Cabinet frame bolts (9/16") can be loosened to shift the panels if needed to level the cabinet to the ground surface or square up the door. The cabinet lower corners have foot-pads with a pre-drilled 13/16" hole that can be used to anchor the cabinet if required. It is suggested that the cabinet be anchored to the mounting surface. Check with your authority having jurisdiction to confirm anchoring is required. Use the appropriate hardware for the mounting surface. Mounting hardware not included.
1 year warranty against manufacturing defects.
Ships fully assembled on a pallet by freight truck. Loading dock or forklift required for delivery. If neither are available please request liftgate delivery at time of order.
