12 Cylinders - Large Oxygen & Medical Gases (H Tanks) - Fire Lined - Self-Closing Doors - Cylinder Storage Cabinet
In stock
Model #
CBMG309HFLSA
$3,230.00
Call 1-877-805-8650 to order or request quote by phone.
Status:
Built to order
Shipping:
Ships 4-6 weeks from order date. You will be sent a tracking # upon shipment.
Capacity: 12
Supported cylinder sizes: H (9.25" diameter up to 60" tall)
Doors: 2 self-closing doors
Supported cylinder sizes: H (9.25" diameter up to 60" tall)
Doors: 2 self-closing doors
Cabinet dimensions:
43"w x 34"d x 65"h
Oxygen Storage Cabinet Features:
- 2 doors - self-closing
- Fire-lined walls provide estimated 60 Minute fire protection
- NFPA Code 30, 99, 101 and OSHA compliant
- Lockable flush-mounted paddle handle, includes 2 keys
- One chain included to secure cylinders inside the cabinet
- Doors have full-length piano hinges
- All-welded, galvannealed steel construction
- Finished in 2 coats of OSHA safety green color urethane paint
- 18-gauge steel for durability, longevity and fire safety
- Double-walled construction shields cylinders from heat, sparks and flame
- Two 2" vents with covers
- Four adjustable leveling feet provide a sturdy base
- English and Spanish warning labels
- Includes manufacturer's 15-year warranty
- Product weight: 550 lbs
12 Cylinders - Large Oxygen & Medical Gases (H Tanks) - Fire Lined - Self-Closing Doors - Cylinder Storage Cabinet
Model #
CBMG309HFLSA
Description:
This oxygen gas cylinder storage cabinet is designed to hold up to 12 size H cylinders (9.25" diameter up to 60" tall). This type of cabinet is used in hospitals and nursing homes to allow the safe, compliant storage of full medical gases. It has a double-walled, heavy-gauge construction with gypsum particle board lining to provide an estimated 60 minutes of fire protection to the cylinders from heat, sparks and flame. There are two 2" vents with covers. One is located on the side near the bottom and the other is on the opposite side near the top to provide cross ventilation. The self-close doors have a lockable, flush-mounted paddle handle and use full length piano hinges with two keys. Also included is one chain to secure the cylinders inside the cabinet. Four adjustable leveling legs allow the cabinet to be leveled on uneven surfaces. The cabinet is coated in OSHA safety green urethane paint for full cylinder storage. Other cabinet paint colors available: white for partial cylinder storage and red for empty cylinder storage. Contact USA Safety customer service for more information. Cylinders not included.
This oxygen gas cylinder storage cabinet is designed to hold up to 12 size H cylinders (9.25" diameter up to 60" tall). This type of cabinet is used in hospitals and nursing homes to allow the safe, compliant storage of full medical gases. It has a double-walled, heavy-gauge construction with gypsum particle board lining to provide an estimated 60 minutes of fire protection to the cylinders from heat, sparks and flame. There are two 2" vents with covers. One is located on the side near the bottom and the other is on the opposite side near the top to provide cross ventilation. The self-close doors have a lockable, flush-mounted paddle handle and use full length piano hinges with two keys. Also included is one chain to secure the cylinders inside the cabinet. Four adjustable leveling legs allow the cabinet to be leveled on uneven surfaces. The cabinet is coated in OSHA safety green urethane paint for full cylinder storage. Other cabinet paint colors available: white for partial cylinder storage and red for empty cylinder storage. Contact USA Safety customer service for more information. Cylinders not included.
MPN: MG309HFL
Get more information:
Call 1-877-805-8650 (M-F, 9-5 p.m. CST) if you have questions about this product.
Call 1-877-805-8650 (M-F, 9-5 p.m. CST) if you have questions about this product.
The fully assembled cabinet is freestanding and has four adjustable zinc plated leveling legs to level it on the floor surface.
Includes manufacturer's 15 year structural limited warranty against defects in materials and workmanship from the date of purchase.
Ships fully assembled on a pallet by freight truck. Loading dock or forklift required for delivery. If neither are available please request liftgate delivery at time of order.
